Coil Technology: Built-in bidirectional peak limiting diode suppressor
Control Circuit Voltage Limits: 0.1...0.25 Uc drop-out at 60 °C, DC, 0.7...1.25 Uc operational at 60 °C, DC
Time Constant: 28 ms
Inrush Power in W: 5.4 W at 20 °C
Hold-in Power Consumption in W: 5.4 W at 20 °C
Auxiliary Contacts Type: Type mechanically linked (1 NO + 1 NC) conforming to IEC 60947-5-1, Type mirror contact (1 NC) conforming to IEC 60947-4-1
Signalling Circuit Frequency: 25...400 Hz
Minimum Switching Current: 5 mA for signalling circuit
Minimum Switching Voltage: 17 V for signalling circuit
Non-Overlap Time: 1.5 ms on energisation between NC and NO contact, 1.5 ms on de-energisation between NC and NO contact
Insulation Resistance: > 10 MOhm for signalling circuit
height: 77 mm
width: 45 mm
depth: 95 mm
product weight: 0.48 kg
