TECHNICAL DATA
Colour
Red
Rated current (A)
16-125
IP degree
IP66/IP67/IP68/IP69
No. of poles
Mechanical resistance
IK09
Reference h
11
Type
Straight connector
Rated voltage
440 - 460 V
Frequency
60 Hz
Terminal tightening capacity
6-16mm² flexible cables - 6-25mm² rigid cables
Cable clamp tightening capacity
17.9-37 mm
Operating temperature
-25 +55 °C
Type of wiring
Mantle terminal
Type of material
Halogen-free in compliance with EN 60754-2
Electrocod
2211
Glow wire test
850 °C (active parts) - 650 °C (passive parts)
Total number of operations
> 2000
Breaking capacity at 1.1 Un
79 A
Insulation resistance
> 10 MΩ
Thermo-pressure with ball
125 °C (active parts) - 80 °C (passive parts)
