Conductor Size Nominal mm² 0.50 0.75 1.00 1.50
Class Of Conductor Class-2 or Class-5
Conductor Resistance Max Ohm/km P
39.0 T
40.1 P
29.6 T
26.8 P
18.4 T
20 P
12.20 T
12.70
Insulation Resistance Min
(BIS:5308) Mohm x
km PVC : 25 PE : 5000
Mutual Capacitance
Core to Core
Core to Screen Max Pf/mtr PVC
250
400 PE
80
120
L.R. Ratio Max Micro H/ohm 25 25 25 40
Test Voltage
Core to Core
Core to Screen
Core to Armored –
V
V
V –
1500 volt- 5 minutes
500 volt- 3 minutes
1000 volt- 3 minutes
