DC Voltage 0.1 mV - 600 V (± 0.5% + 2)
AC Voltage 0.1 mV - 600 V (± 1.0% + 3) True-RMS
DC Current 0,001 A - 10 A (± 1.0% + 3)
AC Current 0,001 A - 10 A (± 1.5% + 3) True-RMS
Resistance 0.1 Ω ~ 40 MΩ (± 0.9% + 1)
Capacitance 1 nF ~ 9.999 µF (± 1.9% + 2)
Frequency 0.01 Hz ~ 50 kHz (± 0.1% + 2)
When measuring currents, values up to 20 A can be measured for max 30 seconds. Afterwards the meter needs to cool for at least 10 minutes.
Input protection IEC 61010-1 600 V CAT III, Pollution Degree 2
Display 6,000 counts
Battery lifespan ~400 hours
Dimensions 167 x 84 x 550 mm
Weight 550 g
