Display 2000 counts ● Auto Power Off ● Transistor hFE 0~1000 ● Diode Open Voltage 3.0V ● Continuity Buzzer <50Ω ● Data Hold ● Low Battery Display ● Power Supply : 1x9V 6F22 Battery ● Product Size : 195mmx95mmx55mm/7.67"x3.74"x2.16" ● Product Weight : 366g/0.8lb ● Certificate : RoHS ● Safety Rating : CATII 1000V / CATIII 600V Specifications Range Resolution Accuracy DC Voltage 200mV/2V/20V/200V 0.1mV/1mV/10mV/100mV ±(0.5%+2) 1000V 1V ±(0.8%+2) AC Voltage 200mV 100μV ±(1.2%+3) 2V 1mV ±(0.8%+3) 20V/200V 10mV/100mV ±(0.8%+3) 750V 1V ±(1.2%+3) DC Current 20μA 0.01μA ±(2.0%+5) 200μA/2mA/20mA 0.1μA/1μA/10μA ±(0.8%+1) 200mA 0.1mA ±(1.5%+1) 10A 10mA ±(2.0%+5) AC Current 20μA 0.01μA ±(2.0%+5) 200μA 0.1μA ±(1.0%+5) 2mA 1μA ±(1.0%+5) 20mA 10μA ±(1.0%+5) 200mA 0.1mA ±(1.8%+5) 10A 10mA ±(3.0%+7) Resistance 200Ω 0.1Ω ±(0.8%+3) 2kΩ/20kΩ/200kΩ/2MΩ 1Ω/10Ω/100Ω/1kΩ ±(0.8%+2) 20MΩ 10kΩ ±(1.0%+2) 200MΩ 100kΩ ±(6.0%+10)
